AT staple 10mm RAL9005

tap image to zoom

Description

AT staple galvanized, bulk, RAL color

Read more Read less

Applications

Furnitures, Upholstering, Insulation boards, Felt, Casing, Shoes

Read more Read less

Request information

Specifications

Identifiers

Article number: AT06BACP9005
GTIN: 8715274015927

Technical specifications

Collation angle: 0 °
Collation type: Glue collated
Wire material: Carbon steel standard tensile
Gauge: 21

Fastener specifications

Finish: Regular galvanised
Coating: Plain
Application environment: Indoor
Point type: Chisel
Pointangle: 90 °
Staple type: Light wire staple
Staple thickness: 0.69 mm
Staple wire size: 0.83 mm
Staple crown width: 12.7 mm
Staple inside width: 11.3 mm
Staple serie: AT staple
Amount fasteners on strip/coil: 150 - 150
Staple length: 10.0 mm

Non-technical specifications

Package quantity: 16000

Logistical specifications

Net weight: 2.08 kg

Downloads

AT06BACP9005_en_CommercialProductSheet_1.4_1752319418745 PDF 1 Mb
