High density drywall to steel screw SQ2 weatherex 4,2x38mm

tap image to zoom

Description

Drywall to steel screw, wheaterex II, square

Read more Read less

Applications

Drywall to heavy steel

Read more Read less

Norm

Harmonized standard EN 14566:2008+A1:2009

Request information

Specifications

Identifiers

Article number: 42TC38MW
GTIN: 8715274045733

Technical specifications

Collation type: Plastic collated
Wire material: Carbon steel standard tensile
Rotations per minute: 2300, 2500, 3000, 3300 RPM

Fastener specifications

Finish: Weatherex II
Application environment: Outdoor
Head diameter: 4.2 mm
Point type: Self drilling
Pointangle: 110 °
Screw head type: Wafer head
Screw recess: Square 2
Screw thread type: Tek
Amount fasteners on strip/coil: 50 - 50
Screw length: 38.0 mm
Screw diameter: 4.2 mm

CeSpecifications

DOP No: 42TC38MW
Material notification on CE label: Non-alloy steel
Service class: 3
Inner threaded diameter: 3.3 mm
Threaded/profiled length: 33.0 mm
Harmonized standard: EN 14566:2008+A1:2009

Non-technical specifications

Package quantity: 1000

Downloads

42TC38MW_en_CommercialProductSheet_1.5_1757440000411 PDF 1 Mb
42TC38MW_en_DeclarationOfPerformanceDoP_1.2eu_1757440069720 PDF 59 Kb
